MaxxECU GEN2 TRACK

MaxxECU GEN2 TRACK

The GEN2 TRACK is engineered for high-performance engines that demand precision. With V8 support, dual wideband lambda, dual knock control, high-speed logging, and advanced tuning capabilities, it gives you the confidence to push harder. It comes with the intuitive MTune software for seamless tuning and real-time monitoring, plus full control with the wireless MDash Android app, taking your setup to the next level.


Analog, digital or PULSE inputs

16 analog inputs and 6 PULSE inputs


550 kPa MAP Sensor

Built-in MAP sensor supporting up to 4.5 bar / 65 PSI of boost.


Waterproof IP68

Black powder-coated aluminium case with IP68 water-protection rating.

Selected features

Volumetric efficiency fuel tuning
Boost control (triple stage)
Launch control
Anti-lag with cooldown features
Traction and power management control
Shift cut and sequential gearbox control
Flexfuel
Nitrous with purge and multiple stage control
Knock control
VANOS / VVTi, variable valve timing
Auto trans (4L60/65/80/85E, A340/341/650E)
OEM CAN integrations
DSG / DCT / 8HP CAN gearbox control
Internal log up to 1000Hz
Waterproof IP68
550 kPa MAP sensor (4.5 bar / 65 PSI boost)
8 injector outputs
8 ignition outputs
Dual Wideband Lambda
Dual CAN
Dual knock
WIFI and Bluetooth
Target Engines of MaxxECU GEN2 TRACK
  • All 1-12 cylinder engines (2/4-stroke)
  • Up to 8 cylinders fully sequentially
  • Up to 12 cylinders in wasted spark
MaxxECU GEN2 TRACK inputs
  • 6 pulse inputs (VR/HALL): 2 with selectable 5/12V power supply, all with selectable pullups.
  • 16 Analog inputs (selectable pullups)
  • Dual wideband lambda (LSU 5.2/4.9/4.2)
  • Dual knock sensor input
MaxxECU GEN2 TRACK outputs
  • 8 injectors (Peak-hold high/low impedance) / GP outputs
  • 8 IGN / GP outputs (selectable +5V/12V/GND)
  • 8 GP Outputs (GND)
  • 4 GP Outputs (+12V)
  • 4 GP Outputs (H-bridge/E-Throttle)
MaxxECU GEN2 RACE technical
  • Superseal 1.0 connectors
  • 550 kPa MAP sensor (4.5 bar / 65 PSI boost), user-serviceable, with BSP 1/8 thread
  • 3-axis accelerometer (up to 8 G)
  • ARM dual core CPU
  • 6-22V operating voltage
  • 8GB internal log capacity, 1000Hz, all 2000+ channels
  • USB-C 480mbit/s (MTune PC communication)
  • USB-C 12mbit/s (tablet charging)
  • WIFI communication with MTune
  • Bluetooth connectivity with MDash
  • Dual CAN bus for expansion modules, OEM vehicle CAN, OBDII, CAN gearbox control
  • Resolution on ignition: 0.1 degrees
  • Resolution on injectors: 0.001 ms
  • Performs fuel and ignition calculations 3,000 times per second.
  • 2000Hz sampling rate on analog/digital inputs
  • Weight: 545g
  • 206x138x35mm including protruding connectors
  • Black powder-coated aluminium case
  • All inputs and outputs are safeguarded against overvoltage, reverse polarity, and short circuits.
